3W High-power LED MLT-HP-03-03700DXX
Brief Introduction
This is the specification of 3W high power LED. Except this model, high power LED supplier and manufacturer Moonlight also provide 1W high power LED.
High-power LEDs (HP-LEDs) can be driven at currents at hundreds of mA, compared with the tens of mA for other LEDs. LED power densities can reach a very high value. Since overheating is destructive, the high-power LEDs must be mounted on a heat sink to allow for heat dissipation. If the heat from a high-power LED is not removed, the device fails in seconds. High efficacy low forward voltage and high quality color rendering makes Moonlight high power LED could be used in a broad range of applications.
Feature
- Luminous flux ranging from 160lm-220lm.
- Various configurations of different voltage and die count to meet a wide range of application requirements.
- Deliver high efficacy and quality of light for distributed light source.
- Excellent color Reproduction.
- Available in a broad range of CCTs from 2600K to 6700K.
- RoHS complaint.
- Low thermal resistance.
- Environment-friendly.
- Long life span and high reliability.
Mechanical Dimensions
Parameter
| Model No. | 3W High-power LED MLT-HP-03-03700DXX |
| LED Package | Ref. to the mechanical dimension |
| Typical Forward Voltage | 3.5V |
| DC Forward Current | 700mA |
| Typical Power Dissipation | 3W |
| Typical Luminous Flux | 160lm-220lm |
| CRI | >80Ra |
| CCT Range | 2600K-6700K |
| Emitting Color | Warm White/Neutral White/Cool White |
| Viewing angle | 120° |
| Operating Temperature | -30℃～+60℃ |
| Storage Temperature | -40℃～+80℃ |
Application
Moonlight advanced packaging technology and spectrum tuning technology creates emphasis on the appearance of lighting. 3W high power LED is suitable for commercial lighting and LED outdoor lighting, such as LED bulb, LED spot lights, LED downlight, LED track light, LED floodlight, LED high bay light, LED wall pack light, LED street light, etc. It is also widely used as backlight, traffic light, LED display and other electric products.
