3V 60mA 0.2W Blue SMD 2835 LED MLT-SMD-2835-03060MLB
3V 60mA 0.2W Blue SMD 2835 LED MLT-SMD-2835-03060MLB
The 3V 60mA 0.2W blue SMD 2835 LED from SMD 2835 LED supplier and manufacturer Moonlight is a collection of compact devices, 2.8mm*3.5mm, that allows for design freedom and provides a superior overall system solution when a project requires high flux output and good efficacy. The Moonlight 2835 SMD LED is color targeted for application needs and delivers efficiency and reliability for a variety of applications.
The SMD LED Module (surface-mount device light-emitting diode module) is a type of LED module that uses surface-mount technology (SMT) to mount LED chips on printed circuit boards (PCB). It is a self-contained surface-mount LED device designed either to function on its own or to plug into a compatible unit. The types of SMD LED Modules are distinguished by the dimensions of the LED package. The package dimension of SMD LED 2835 is 2.8mm*3.5mm.
The monochroic SMD 2835 LED family includes 2V 60mA 0.2W Red SMD 2835 LED, 3V 60mA 0.2W Green SMD 2835 LED and 3V 60mA 0.2W Blue SMD 2835 LED.
Feature
- Compact package size at 2.8mm*3.5mm.
- Various configurations of different voltage and die count to meet a wide range of application requirements.
- Deliver high efficacy and quality of light for distributed light source.
- Excellent color Reproduction.
- Available wave length range of 465nm-475nm.
- RoHS complaint.
- Low thermal resistance.
- Environment-friendly.
- Long life span and high reliability.
Mechanical Dimensions
Parameter
| Model No. | 3V 60mA 0.2W Blue SMD 2835 LED MLT-SMD-2835-03060MLB |
| LED Package | 2.8mm*3.5mm |
| Typical Forward Voltage | 3.0V |
| DC Forward Current | 60mA |
| Typical Power Dissipation | 0.2W |
| Typical Luminous Flux | 2lm-4lm |
| Wave Length | 465nm-475nm |
| Emitting Color | Blue |
| Viewing angle | 120° |
| Operating Temperature | -40℃～+85℃ |
| Storage Temperature | -40℃～+100℃ |
Application
Moonlight advanced packaging technology and spectrum tuning technology creates emphasis on the appearance of lighting. Our 3V 60mA 0.2W SMD 2835 LED is suitable for SMD type indicator, LED module, LED strip, LED bar and other decoration lighting applications.
